V8 Supra MK3 1UZ Twin Turbo from Germany

The 1UZFE EGR Delete Kit is available for sale here.
Turbo Manifolds

Hey Guys,

today I will post some more pics of the custom turbo manifolds

left hand side manifold with turbo









Last edited:
Custom Exhaust Manifolds

...rhs mainfold + turbo



Me at the milling machine


both manifolds and turbos





Last edited:
Oil Nozzles

But first I want to show you some pics of the preparation for the oil nozzles.

I did it myself on my milling machine. First I milled off some material of the main oil duct so I got a surface for the nozzles.



Then drilling a hole for the nozzle







Last edited:
I like how you moved the alternator to the opposite side to free up some room instead of going front and center with it. Are my eyes deceiving me or was there some creative use of a BFH on the frame rails? Will you be using anything in the oil sump to minimize aeration of the oil? --Mike

I like how you moved the alternator to the opposite side to free up some room instead of going front and center with it. Are my eyes deceiving me or was there some creative use of a BFH on the frame rails? Will you be using anything in the oil sump to minimize aeration of the oil? --Mike

Hey Mike!
Thanks for the feedback about the alternator.
But please explain me what you mean with BFH. Do you mean the aluminium plate where I fixed the return pulleys for the belt?

And I use the OEM baffle in the oil sump. Hope that's what you asking for.

Alex

Hey Mike!
Thanks for the feedback about the alternator.
But please explain me what you mean with BFH. Do you mean the aluminium plate where I fixed the return pulleys for the belt?

And I use the OEM baffle in the oil sump. Hope that's what you asking for.

Alex

BFH=Big Fuc*ing Hammer


Love the proper useage of safety glasses!!! (i end up doing it all the time too)
Love the oiler install... will be on my to do list if i ever crack into mine... any fear of loosing oil pressure to the upper end?

all and all awesome fabrication
should be wicked when your done!!!

BFH=Big Fuc*ing Hammer


Love the proper useage of safety glasses!!! (i end up doing it all the time too)
Love the oiler install... will be on my to do list if i ever crack into mine... any fear of loosing oil pressure to the upper end?

all and all awesome fabrication
should be wicked when your done!!!


Haha...!!! :D My safty glasses has so much scratches on it so it makes more sense to use it as a forehead-safer. :rolleyes:
Thanks for the "BFH" explanation! Now I know what Mike meant. Yes I used a BFH and a burner on the frame rails to make some room for intercooling pipings. But now I don't need that room no longer because I decided to go another way.

The goul, the project is already done and you can have a look at my dyno thread if you are interessted...and yes it's f**king wicked! :cool:

I can tell you something about the oil pressure. It's about 1,5 bar @ idle and about 3-3,5 bar till 7400 rpm with 10W-60 synthetic oil. I think it would be a little bit higher without the oil nozzles.

Thanks
Alex

Very nice project you have there, Alex. I just love turbocharged 1UZFE. It's a complete different beast from stock.

Crank Sensor Trigger Wheel

Hey folks,

today I will update you with some more pics.
Let's have a look at my new crank sensor trigger wheel. I switched from the stock crank sensor to an aftermarket hall sensor. I also changed the cam sensor to a hall sensor.

New trigger wheel vs. stock tw






Last edited:
Engine+Turbo Manifolds+Turbos

The turbo manifolds after the heat treatment and painting...



Last edited:
Oil Cooler

Here some pics of the custom oil cooler, oil filter relocator, oil adapter plate, MOCAL oil thermostat and piping...






Last edited:
