it will be a new converter, it will be Neal Chance 100% instead of a Neal Chance/TCE hybrid, we think that is letting us down a little bit now. yeah, n Vince is a whiz with the 8860, there is noone better with it then him, so hopefully it's all win win.
thanks. they have a .065'' wall so if my maths is correct 1.37''
I guess anyone wondering how much power 1.5" primaries can support on this V8 turbo? Well, at least 1200hp... And you intend to use these for your 1500hp target? Fits in with one school of thought that suggests the turbine and housing are more restrictive than the primaries so they are rarely the choke point.
it could definitely be made alot more efficient, Kyle had a little look at the exhaust manifolds a lil while back, he said it works, so that's the main thing
no real thought went into them, they were just knocked up quick so the car could be engineered, then a new set would be made. these worked well so we ended up keeping them.
it will be a new converter, it will be Neal Chance 100% instead of a Neal Chance/TCE hybrid, we think that is letting us down a little bit now. yeah, n Vince is a whiz with the 8860, there is noone better with it then him, so hopefully it's all win win.
thanks. they have a .065'' wall so if my maths is correct 1.37''
I guess anyone wondering how much power 1.5" primaries can support on this V8 turbo? Well, at least 1200hp... And you intend to use these for your 1500hp target? Fits in with one school of thought that suggests the turbine and housing are more restrictive than the primaries so they are rarely the choke point.
Agree totally.
So XR8tt is that 330 cid" If so you are running the same size primaries on a 5.4 liter Ford as Forar is on his 4.0 Lexus/Toyota? Very interesting.
Regarding backpressure the higher velocity (vs larger primaries) actually has lower dynamic pressure than the same mass flow at a lower velocity. Also a larger pipe has more surface area to conduct heat (also imPORTant in the PORT which affects cooling and coolant) combined with more time for the transfer to happen. I for one prefer the heat to reach the turbine rather than be lost to the port and primary.
Obviously it is possible to go too small but especially on any engine where boost response is important... too large is not helping anything... quite the contrary.
So XR8tt is that 330 cid" If so you are running the same size primaries on a 5.4 liter Ford as Forar is on his 4.0 Lexus/Toyota? Very interesting.
Regarding backpressure the higher velocity (vs larger primaries) actually has lower dynamic pressure than the same mass flow at a lower velocity. Also a larger pipe has more surface area to conduct heat (also imPORTant in the PORT which affects cooling and coolant) combined with more time for the transfer to happen. I for one prefer the heat to reach the turbine rather than be lost to the port and primary.
Obviously it is possible to go too small but especially on any engine where boost response is important... too large is not helping anything... quite the contrary.
Last edited:
1.5'' will more than likely be used on the new engine. 1.5'' should be more than enough for 1500-1600hp. funnily, we were discussing turbo manifolds on Thursday night with the fabricator. everyone has ther own theories and what should be done and what will work the best. the current headers are doing the job, they were just a set knocked up one Saturday afternoon in the garage
they have been working thus far, but, they are far from a super efficient exhaust manifold, the new design we were discussing with the fabricator will be much better. will discuss that more when do a thread for the new motor build.
they have been working thus far, but, they are far from a super efficient exhaust manifold, the new design we were discussing with the fabricator will be much better. will discuss that more when do a thread for the new motor build.
XR8tt
Active Member
I would say the merge or collector could be better ?? Helps spool with large-sh turbo'd and takes advantage of any pulse at low-sh rpm .. Diamond shape inside collector keeps velocity of each cylinder ! My friend made his up this way on another 4.0 engine !! Trouble is we tend to do other mods at the same time !! Not easy to compare ? But going to larger turbo and spool is about the same if not quicker !! Had these discussions with Kyle ( 6 boost) years ago .. They make good manifolds .. $$ ..
Last edited:
it could definitely be made alot more efficient, Kyle had a little look at the exhaust manifolds a lil while back, he said it works, so that's the main thing
no real thought went into them, they were just knocked up quick so the car could be engineered, then a new set would be made. these worked well so we ended up keeping them.
