Hey guys
Just finished fabricating up my bell housing adapter for my 1uz swap into my 84 supra. Im in the habit of making a few parts at the same time, so that way if I have to scrap one for some reason I will have backups. Well this has lead me to have an extra adapter plate.
This was fabricated using these plans
http://www.v-eight.com/tech_forum/viewtopic.php?f=40&t=753
(and yes i plan to make a donation from the proceeds from this sale)
The adapter plate was laser cut from 3/8" A36 steel
The centering plate was laser cut from 3/16" A36 steel
They were welded together using steel dowels for correct alignment before the holes were finish drilled and tapped
The plates were also shot-peened before finish drilling and tapping (but after welding)
The plate you see here in the pictures is the one you will receive
Im asking $200 shipped any where in the 48 (us) states
![11-23-09002.jpg 11-23-09002.jpg](https://www.lextreme.com/forums/data/attachments/17/17430-e0a85fc6dd3f66dc5cd9c3bcec670f89.jpg?hash=4Khfxt0_Zt)
![11-23-09003.jpg 11-23-09003.jpg](https://www.lextreme.com/forums/data/attachments/17/17431-5d4e7be918545d240261205742fcb0da.jpg?hash=XU576RhUXS)
![11-23-09005.jpg 11-23-09005.jpg](https://www.lextreme.com/forums/data/attachments/17/17432-b38186cad435addbd3358fdeb82ce268.jpg?hash=s4GGytQ1rd)
![11-23-09006.jpg 11-23-09006.jpg](https://www.lextreme.com/forums/data/attachments/17/17433-4240f250b1a00fe01c696d3543a205d2.jpg?hash=QkDyULGgD-)
![11-23-09007.jpg 11-23-09007.jpg](https://www.lextreme.com/forums/data/attachments/17/17434-1b3a0aa549d7c5a6237db99bb8465c3b.jpg?hash=GzoKpUnXxa)
